Model	d	A	C	D1	D2	D3
C16E-0	15.918	12.2	7	33	34.2	41

Operation Conditions：

Temperature：-35℃~ 135℃
Pressure:≤0.3MPa
Speed : ≤6800r/min
Medium：clean water, gas engine antifreeze

Standard Materials：

Parts & Spring ：Stainless Steel
Rubber parts ：NBR & HNBR
Stationary Ring ：Carbon/Sillicon Carbide
Rotary Ring ：Sillicon Carbide

Applications：

◆ Auto cooling pump
◆ Household pump
◆ General pump
◆ Small-typed centrifugal pump

Specification:

Temperature： - 35℃ ~ 135℃
Pressure : ≤0.3MPa
Speed : ≤6800r/min
