ERVING SEAL ENTERPRISES CO., LTD
d | D | D1 | L | L1 |
10 | 20 | 18.1 | 20.5 | 5.5 |
11 | 22 | 20.6 | 23.5 | 5.5 |
12 | 22 | 20.6 | 23.5 | 5.5 |
13 | 25 | 23.1 | 28 | 6 |
14 | 25 | 23.1 | 28 | 6 |
15 | 29 | 26.9 | 30 | 7 |
16 | 29 | 26.9 | 30 | 7 |
17 | 29 | 26.9 | 30 | 7 |
18 | 33 | 30.9 | 32 | 8 |
19 | 33 | 30.9 | 33 | 8 |
20 | 33 | 30.9 | 33 | 8 |
21 | 38 | 35.4 | 33 | 8 |
22 | 38 | 35.4 | 33 | 8 |
23 | 38 | 35.4 | 35 | 8 |
24 | 38 | 35.4 | 35 | 8 |
25 | 40 | 38.2 | 35.5 | 8.5 |
28 | 46 | 43.3 | 39 | 9 |
29 | 46 | 43.3 | 39 | 9 |
30 | 46 | 43.3 | 39 | 9 |
32 | 46 | 43.3 | 39 | 9 |
33 | 48 | 53.5 | 50.5 | 11.5 |
35 | 50 | 53.5 | 50.5 | 11.5 |
38 | 58 | 60.5 | 50.5 | 11.5 |
40 | 58 | 60.5 | 50.5 | 11.5 |
Operation Conditions:
Temperature:-20℃~ 100℃
Pressure:≦8㎏ / c㎡
Speed:≦15 m/s
Standard Materials:
Stationary Ring :Ceramic / SIC / TC
Rotary Ring:Carbon / SIC / TC
Secondary Seal:NBR / EPDM / VITON
Metal parts:SUS 304 / SUS316
Applications:
◆ Water pumps
◆ Circulation pumps
◆ Household pumps
