ERVING SEAL ENTERPRISES CO., LTD
Shaft D | A | H | L | E |
1/2 | 25.4 | 26.97 | 16.66 | 7.925 |
5/8 | 31.75 | 30.937 | 18.29 | 10.287 |
3/4 | 34.925 | 34.112 | 18.29 | 10.287 |
1 | 41.275 | 42.85 | 20.63 | 11.1 |
Operation Conditions:
Temperature:-20℃~ 200℃
Pressure:≦5 ㎏ / c㎡
Speed:≦10 m/s
Medium:Clean water, Lower alkali liquid, Warm water, Oil and weakly-corrosive mediums
Standard Materials:
Stationary Ring :Ceramic / SIC / TC
Rotary Ring:Carbon / SIC / TC
Secondary Seal:NBR / EPDM / VITON
Metal parts:S.S / SUS 304 / SUS316
Applications:
◆ Household pumps
◆ Gear pump
◆ Mixer
Specification:
Temperature:-20℃~ 200℃
Pressure:≦5 ㎏ / c㎡
Speed:≦10 m/s
