d | d3 | d7 | L2 | L4 |
14 | 30 | 30 | 5 | 5 |
15 | 30 | 30 | 5 | 5 |
d | D3 | D7 | L2 | L4 |
20 | 38 | 38/44 | 9 | 8 |
25 | 44 | 44/50 | 9 | 8.5 |
30 | 50 | 50/57 | 9.5 | 9.5 |
35 | 58 | 64 | 9.5 | 10.5 |
40 | 64 | 70 | 11 | 9 |
45 | 66 | 70 | 10 | 9 |
50 | 72 | 80 | 10 | 9 |
Operation Conditions:
Temperature:-50℃~ 200℃
Pressure:≦5㎏ / c㎡
Speed:≦10 m/s
Medium:Oil, Water and waste water
Standard Materials:
Stationary Ring :Ceramic / SIC / TC
Rotary Ring:Carbon / SIC / TC
Secondary Seal:NBR / EPDM / VITON
Metal parts:SUS 304 / SUS316
Applications:
◆ Industrial pumps
◆ Submersible pumps
◆ Chemical industry
◆ Engine pumps
◆ Circulating pumps
Specification:
Temperature:-50℃~ 200℃
Pressure:≦5㎏ / c㎡
Speed:≦10 m/s
