ERVING SEAL ENTERPRISES CO., LTD
D | D1 | D2 | D3 | D4 | L | L1 | L2 | L3 | L4 | L5 | L6 |
20 | 34 | 54 | 42 | 55 | 38.8 | 14 | 4 | 11 | 10 | 3 | 20 |
25 | 39 | 57.2 | 45 | 58 | 38.8 | 14 | 4 | 11 | 10 | 3 | 20 |
30 | 44 | 63.5 | 50 | 63 | 39.6 | 14 | 4 | 11 | 10 | 3 | 20 |
35 | 49 | 66.7 | 55 | 68 | 45.1 | 14 | 4 | 11 | 10 | 3 | 25 |
40 | 56 | 76.2 | 60 | 74 | 46 | 15 | 5 | 13 | 10 | 4 | 25 |
45 | 61 | 79.4 | 65 | 79 | 46 | 15 | 5 | 13 | 10 | 4 | 25 |
50 | 66 | 85.7 | 72 | 87 | 48.3 | 18 | 6 | 13 | 12 | 5 | 25 |
55 | 71 | 88.9 | 80 | 95 | 48.3 | 18 | 6 | 13 | 12 | 5 | 25 |
60 | 78 | 106.4 | 86 | 101 | 63.1 | 18 | 6 | 13 | 12 | 5 | 35 |
65 | 83 | 109.5 | 92 | 107 | 63.1 | 21 | 7 | 13 | 14 | 6 | 35 |
70 | 90 | 115.9 | 96 | 111 | 63.9 | 21 | 7 | 13 | 14 | 6 | 35 |
75 | 95 | 122.2 | 101 | 116 | 63.9 | 23 | 7 | 13 | 16 | 6 | 35 |
80 | 100 | 133.4 | 106 | 121 | 78.2 | 23 | 7 | 13 | 16 | 6 | 45 |
85 | 105 | 139.7 | 114 | 129 | 78.2 | 23 | 7 | 13 | 16 | 6 | 45 |
90 | 110 | 142.9 | 122 | 137 | 79 | 23 | 7 | 14 | 16 | 6 | 45 |
95 | 115 | 149.2 | 127 | 142 | 79 | 23 | 7 | 14 | 16 | 6 | 45 |
100 | 120 | 152.4 | 132 | 147 | 79 | 23 | 7 | 14 | 16 | 6 | 45 |
Operation Conditions:
Temperature:-10℃~ 120℃
Pressure:≦4.5 ㎏ / c㎡
Speed:15 m/s
Medium:Sulfuric acid, Hydrochloric acid, Phosphoric acid, Acetic acid, Alkalies and corrosive liquids
Standard Materials:
Stationary Ring :Ceramic / SIC
Rotary Ring:TEFLON / SIC
Secondary Seal:TEFLON
Metal Parts:Steel
Specification:
Temperature: - 10℃ ~ 120℃
Pressure:≦4.5 kg/c㎡
Speed:≦15 m/sec
