ERVING SEAL ENTERPRISES CO., LTD
d | d3 | d6 | d7 | L | L4 |
14 | 25 | 21 | 25 | 35 | 10 |
16 | 27 | 23 | 27 | 35 | 10 |
18 | 33 | 27 | 33 | 37 | 11.5 |
20 | 35 | 29 | 35 | 37 | 11.5 |
22 | 37 | 31 | 37 | 37 | 11.5 |
24 | 39 | 33 | 39 | 40 | 11.5 |
25 | 40 | 34 | 40 | 40 | 11.5 |
28 | 43 | 37 | 43 | 42.5 | 11.5 |
30 | 45 | 39 | 45 | 42.5 | 11.5 |
32 | 47 | 42 | 48 | 42.5 | 11.5 |
33 | 48 | 42 | 48 | 42.5 | 11.5 |
35 | 50 | 44 | 50 | 42.5 | 11.5 |
38 | 55 | 49 | 56 | 45 | 14 |
40 | 57 | 51 | 58 | 45 | 14 |
43 | 60 | 54 | 61 | 45 | 14 |
45 | 62 | 56 | 63 | 45 | 14 |
48 | 65 | 59 | 66 | 45 | 14 |
50 | 67 | 62 | 70 | 47.5 | 15 |
53 | 70 | 65 | 73 | 47.5 | 15 |
55 | 72 | 67 | 75 | 47.5 | 15 |
58 | 79 | 70 | 78 | 52.5 | 15 |
60 | 81 | 72 | 80 | 52.5 | 15 |
63 | 84 | 75 | 83 | 52.5 | 15 |
65 | 86 | 77 | 85 | 52.5 | 15 |
68 | 89 | 81 | 90 | 52.5 | 18 |
70 | 91 | 83 | 92 | 60 | 18 |
75 | 99 | 88 | 97 | 60 | 18 |
80 | 104 | 95 | 105 | 60 | 18.2 |
85 | 109 | 100 | 110 | 60 | 18.2 |
90 | 114 | 105 | 115 | 65 | 18.2 |
95 | 119 | 110 | 120 | 65 | 17.2 |
100 | 124 | 115 | 125 | 65 | 17.2 |
Operation Conditions:
Temperature:-30℃~ 220℃
Pressure:≦16㎏ / c㎡
Speed:≦20 m/s
Standard Materials:
Stationary Ring :Ceramic / SIC / TC
Rotary Ring:Carbon / SIC / TC
Secondary Seal:VITON / NBR / EPDM
Metal parts:SUS304 / SUS316
Applications:
◆ All types of rotating equipment
◆ Centrifugal pump
◆ Agitators
◆ Most general and light chemical duties
Specification:
Temperature:-30℃~220℃
Pressure:≦16kg/c㎡
Speed:≦20m/sec
