ERVING SEAL ENTERPRISES CO., LTD
d | D | D1 | D3 | L | L1 | L2 | L3 | L4 |
20 | 34 | 36 | 29 | 35 | 35 | 48 | 3 | 13 |
22 | 36 | 38 | 31 | 37 | 35 | 48 | 3 | 13 |
24 | 38 | 40 | 33 | 39 | 35 | 48 | 3 | 13 |
25 | 39 | 41 | 34 | 40 | 35 | 48 | 3 | 13 |
28 | 42 | 44 | 37 | 43 | 35 | 48 | 3 | 13 |
30 | 44 | 46 | 39 | 45 | 35 | 48 | 3 | 13 |
32 | 46 | 48 | 42 | 48 | 35 | 48 | 3 | 13 |
33 | 47 | 49 | 42 | 48 | 35 | 48 | 3 | 13 |
35 | 49 | 51 | 44 | 50 | 35 | 48 | 3 | 13 |
38 | 54 | 58 | 50 | 56 | 38 | 51 | 4 | 13 |
40 | 56 | 60 | 52 | 58 | 38 | 51 | 4 | 13 |
43 | 59 | 63 | 55 | 61 | 38 | 51 | 4 | 13 |
45 | 61 | 65 | 57 | 63 | 38 | 51 | 4 | 13 |
48 | 64 | 68 | 60 | 66 | 38 | 51 | 4 | 13 |
50 | 66 | 70 | 62 | 68 | 39 | 52 | 4 | 13 |
53 | 69 | 73 | 65 | 71 | 40 | 53 | 4 | 13 |
55 | 71 | 75 | 67 | 73 | 40 | 53 | 4 | 13 |
58 | 76 | 83 | 70 | 79 | 41 | 57 | 4 | 16 |
60 | 78 | 85 | 72 | 81 | 41 | 57 | 4 | 16 |
63 | 81 | 88 | 75 | 84 | 41 | 57 | 4 | 16 |
65 | 83 | 90 | 77 | 86 | 41 | 57 | 4 | 16 |
68 | 86 | 93 | 81 | 90 | 41 | 57 | 4 | 16 |
70 | 90 | 95 | 83 | 92 | 42 | 58 | 4 | 16 |
Operation Conditions:
Temperature:-30℃~ 220℃
Pressure:≦ 6㎏ / c㎡
Speed:≦15m/s
Standard Materials:
Stationary Ring : SIC / TC
Rotary Ring:Carbon / SIC / TC
Secondary Seal:VITON / NBR / EPDM
Metal parts:SUS304 / SUS316
Applications:
◆ All types of rotating equipment
◆ Centrifugal pump
◆ Agitators
◆ Most general and light chemical duties
Specification:
Temperature:-20℃~180℃
Speed:≦15m/sec
Pressure:≦6 kg/c㎡
