ERVING SEAL ENTERPRISES CO., LTD
d | D3 | D7 | D | D2 | L | L1 | L2 |
12 | 25 | 29 | 25 | 41 | 58 | 19 | 32 |
16 | 30 | 34 | 29 | 46.5 | 59 | 20 | 30.5 |
22 | 43 | 50 | 39 | 60 | 72 | 20 | 37 |
Operation Conditions:
Temperature(溫度):-30℃~ 180℃
Pressure(壓力):≦1.0 MPA
Speed(轉速):≦10 m/s
Medium(使用環境):
Standard Materials:
Stationary Ring (靜止環):SIC / TC
Rotary Ring(迴轉環):SIC / TC
Secondary Seal:NBR / VITON
Metal parts(金屬零件):SUS304 / SUS316
Specification:
Pressure:≦20kg/c㎡
Speed:≦12m/sec
Temperatur:≦-30℃~200℃
