ERVING SEAL ENTERPRISES CO., LTD
d | D | D1 | L | L1 |
14 | 24 | 25 | 35.2 | 23.2 |
16 | 26 | 27 | 35.2 | 23.2 |
18 | 32 | 33 | 37.7 | 24.2 |
20 | 34 | 35 | 37.7 | 24.2 |
22 | 36 | 37 | 37.7 | 24.2 |
24 | 38 | 39 | 40.4 | 26.9 |
25 | 39 | 40 | 40.2 | 27.2 |
28 | 42 | 43 | 42.7 | 30.2 |
30 | 44 | 45 | 42.6 | 30.7 |
32 | 46 | 48 | 42.6 | 30.7 |
33 | 47 | 48 | 42.6 | 30.7 |
35 | 49 | 50 | 42.6 | 30.7 |
38 | 54 | 56 | 45.1 | 32.2 |
40 | 56 | 58 | 45.1 | 32.2 |
43 | 59 | 61 | 45.1 | 32.2 |
45 | 61 | 63 | 45.1 | 32.2 |
48 | 64 | 66 | 45.1 | 32.2 |
50 | 66 | 70 | 47.6 | 34.2 |
53 | 69 | 73 | 47.6 | 34.2 |
55 | 71 | 75 | 47.6 | 34.2 |
58 | 78 | 78 | 47.6 | 39.2 |
60 | 80 | 80 | 47.6 | 39.2 |
63 | 83 | 83 | 47.6 | 39.2 |
65 | 85 | 85 | 47.6 | 39.2 |
68 | 88 | 90 | 47.6 | 39.2 |
70 | 89 | 92 | 60.2 | 45.7 |
75 | 96 | 97 | 60.2 | 45.7 |
80 | 104 | 105 | 60.2 | 45.2 |
85 | 108 | 110 | 60.2 | 45.2 |
90 | 114 | 115 | 65.2 | 50.2 |
95 | 118 | 120 | 65.2 | 50.2 |
100 | 124 | 125 | 65.2 | 50.2 |
Operation Conditions:
Temperature:-30℃~ 220℃
Pressure:≦40㎏ / c㎡
Speed:≦20 m/s
Medium:Oil, Water and low corrosion mediums
Standard Materials:
Stationary Ring :Ceramic / SIC / TC
Rotary Ring:Carbon / SIC / TC
Secondary Seal:VITON / NBR
v
Metal parts:SUS304 / SUS316
Applications:
◆ Agitator
◆ Compressor
◆ Revolution pump
◆ Mixer
Specification:
Temperature: - 30℃ ~ 220℃
Pressure: ≦ 40 kg/c㎡
Speed: ≦ 20 m/sec
Medium:Oil, Water and low corrosion mediums
