ERVING SEAL ENTERPRISES CO., LTD
D | D1 | D2 | D3 | L | L1 | L2 | L3 |
20 | 34 | 36 | 42 | 64 | 41 | 23 | 18 |
22 | 36 | 38 | 44 | 64 | 41 | 23 | 18 |
24 | 38 | 40 | 46 | 66 | 43 | 23 | 18 |
25 | 39 | 41 | 47 | 66 | 43 | 23 | 18 |
28 | 42 | 44 | 50 | 68 | 45 | 23 | 18 |
30 | 44 | 46 | 52 | 68 | 45 | 23 | 18 |
32 | 46 | 48 | 54 | 68 | 45 | 23 | 18 |
33 | 47 | 49 | 55 | 68 | 45 | 23 | 18 |
35 | 49 | 51 | 57 | 72 | 49 | 23 | 18 |
38 | 54 | 58 | 64 | 78 | 53 | 25 | 20 |
40 | 56 | 60 | 66 | 80 | 55 | 25 | 20 |
42 | 58 | 62 | 68 | 80 | 55 | 25 | 20 |
43 | 59 | 63 | 69 | 80 | 55 | 25 | 20 |
45 | 61 | 65 | 71 | 80 | 55 | 25 | 20 |
48 | 64 | 68 | 74 | 80 | 55 | 25 | 20 |
50 | 66 | 70 | 76 | 85 | 60 | 25 | 20 |
52 | 68 | 72 | 78 | 86 | 61 | 25 | 20 |
53 | 69 | 73 | 79 | 86 | 61 | 25 | 20 |
55 | 71 | 75 | 81 | 86 | 61 | 25 | 20 |
58 | 76 | 83 | 89 | 91 | 63 | 28 | 22 |
60 | 78 | 85 | 91 | 91 | 63 | 28 | 22 |
62 | 80 | 87 | 93 | 91 | 63 | 28 | 22 |
63 | 81 | 88 | 94 | 91 | 63 | 28 | 22 |
65 | 84 | 90 | 96 | 95 | 67 | 28 | 22 |
68 | 87 | 93 | 99 | 97 | 67 | 30 | 24 |
70 | 90 | 95 | 101 | 98 | 68 | 30 | 24 |
75 | 95 | 104 | 110 | 102 | 72 | 30 | 24 |
80 | 100 | 109 | 115 | 103 | 72 | 31 | 25 |
85 | 107 | 114 | 120 | 108 | 77 | 31 | 25 |
90 | 112 | 119 | 125 | 108 | 77 | 31 | 25 |
95 | 119 | 124 | 130 | 113 | 82 | 31 | 25 |
100 | 124 | 129 | 135 | 113 | 82 | 31 | 25 |
Operation Conditions:
Temperature:-60℃~ 250℃
Pressure:≦12 ㎏ / c㎡
Speed:15 m/s
Medium:Oil, Water, Weak acid, Weak alkali, Polymer with high stickiness, Foodstuff, Paper starch and paint
Standard Materials:
Stationary Ring :Carbon / SIC / TC
Rotary Ring: SIC / TC
Secondary Seal:NBR / VITON / TEFLON
Metal parts: SUS 304 / SUS316
Specification:
Temperature:- 60℃ ~ 250℃
Pressure:≦ 12 kg/c㎡
Speed:≦ 15 m/sec
