ERVING SEAL ENTERPRISES CO., LTD
Shaft (d) | d1 | d2 | l | l2 |
30 | 44 | 41 | 26 | 7.5 |
38 | 54 | 52 | 28.5 | 7.5 |
63 | 82.5 | 80 | 32.5 | 8.5 |
Operation Conditions:
Temperature(溫度):-20℃~ 100℃
Pressure(壓力):≦12 ㎏ / c㎡
Speed(轉速):≦20 m/s
Medium(使用環境):Oil, Water, Weak acid, Weak alkali, Polymer with high stickiness, Foodstuff, Paper starch and
paint
Standard Materials:
Stationary Ring (靜止環):SIC / TC
Rotary Ring(迴轉環):SIC / TC
Secondary Seal:NBR / VITON
Metal parts(金屬零件):SUS304 / SUS316
Specification:
Temperature:-20℃~100℃
Pressure:≦12 ㎏/c㎡
Speed:≦20 m/sec
