ERVING SEAL ENTERPRISES CO., LTD
Shaft D | D1 | D2min | D2max | D3 | D4 | L1 | L2 | M10 | M12 | M16 | M20 |
25 | 38 | 40 | 51 | 45 | 94-95 | 48 | 51 | 70 | |||
28 | 41 | 45 | 54 | 48 | 97-98 | 48 | 51 | 73 | |||
30 | 45 | 48 | 57 | 51 | 106-108 | 48 | 51 | 76 | |||
35 | 48 | 50 | 60 | 54 | 106-108 | 48 | 51 | 79 | |||
38 | 54 | 58 | 67 | 60 | 119-121 | 48 | 51 | 87 | |||
40 | 57 | 60 | 70 | 64 | 119-121 | 48 | 51 | 90 | |||
45 | 61 | 64 | 73 | 67 | 125-127 | 48 | 51 | 92 | |||
50 | 67 | 70 | 79 | 73 | 129-130 | 48 | 51 | 103 | 108 | ||
55 | 70 | 73 | 83 | 76 | 151-152 | 48 | 51 | 106 | 111 | ||
60 | 79 | 83 | 92 | 86 | 160-162 | 51 | 54 | 116 | 121 | ||
65 | 86 | 89 | 98 | 92 | 183-184 | 51 | 54 | 122 | 127 | 133 | |
70 | 89 | 92 | 102 | 95 | 195-197 | 51 | 54 | 125 | 132 | 137 | |
75 | 96 | 98 | 108 | 102 | 205-206 | 51 | 54 | 137 | 143 | ||
80 | 99 | 102 | 111 | 105 | 208-210 | 51 | 54 | 140 | 146 | ||
85 | 105 | 108 | 118 | 111 | 214-216 | 51 | 54 | 146 | 152 | ||
90 | 111 | 114 | 124 | 118 | 221-222 | 51 | 54 | 152 | 159 | ||
95 | 114 | 117 | 127 | 121 | 224-226 | 51 | 54 | 155 | 162 | ||
100 | 121 | 124 | 133 | 127 | 227-229 | 51 | 54 | 162 | 168 |
Operation Conditions:
Temperature(溫度):-30℃~ 180℃
Pressure(壓力):≦25kg/c㎡
Speed(轉速):≦23 m/s
Medium(使用環境):Petroleum, Chemical solvents, Weak and medium acids
Standard Materials:
Stationary Ring (靜止環):SIC / TC
Rotary Ring(迴轉環):SIC / TC
Secondary Seal:NBR / VITON
Metal parts(金屬零件):SUS304 / SUS316
Specification:
Temperature:-20℃~200℃
Pressure:≦25kg/c㎡
Speed:≦23m/sec
