ERVING SEAL ENTERPRISES CO., LTD
Model | d | A | C | D1 | D2 | D3 |
7CF-0 | 12 | 8.9 | 7.6 | 26.5 | 30 | 35 |
7CF-3 | 12 | 8 | 8.5 | 26.5 | 30 | 35 |
7CF-4 | 12 | 9.2 | 7.3 | 26.5 | 30 | 35 |
7CF-5 | 12 | 9.6 | 7.6 | 26.5 | 30 | 35 |
7CF-6 | 12 | 8.8 | 7.7 | 26.5 | 38.1 | 43.6 |
7CF-7 | 12 | 9.3 | 8 | 26.5 | 39.5 | 43.6 |
7CF-8 | 12 | 9.3 | 8 | 26.5 | 30 | 35 |
7CF-9 | 12 | 7.7 | 8.5 | 26.5 | 30 | 35 |
7CF-10 | 12 | 7.1 | 8.5 | 26.5 | 30 | 35 |
7CJ-1 | 15.918 | 10.9 | 8 | 31.5 | 36.5 | 41 |
7CJ-2 | 15.918 | 11.84 | 7.1 | 31.5 | 34.2 | 39.5 |
7CJ-5 | 15.918 | 10.4 | 8 | 31.5 | 36.5 | 41 |
7CJ-6 | 15.918 | 10.9 | 8 | 31.5 | 38.1 | 43.6 |
7CJ-7 | 15.918 | 10.8 | 8 | 31.5 | 36.4 | 41 |
7CJ-8 | 15.918 | 10.8 | 8 | 31.5 | 38.1 | 43.6 |
7CJ-9 | 16 | 10.9 | 8 | 31.5 | 36.5 | 41 |
7CJ-10F | 15.918 | 12.3 | 7 | 31.5 | 34.2 | 39.5 |
7C-1-b | 20 | 11.9 | 10.6 | 36.5 | 38.1 | 43.6 |
7C-2-c | 20 | 12 | 10.6 | 36.5 | 52 | 58 |
7C-3 | 20 | 12.5 | 10 | 36.5 | 40 | 46 |
7C-4G | 20 | 14.4 | 8 | 36.5 | 38.1 | 43.6 |
Operation Conditions:
Temperature:-35℃~ 135℃
Pressure : ≤0.3MPa
Speed : φ12≤7200r/min;φ16≤6500r/min;φ20≤5000r/min
Medium:clean water, gas engine antifreeze
Standard Materials:
Parts & Spring :Stainless Steel
Rubber parts :NBR & HNBR
Stationary Ring :Carbon/Sillicon Carbide
Rotary Ring :Sillicon Carbide
Metal parts:SUS 304 / SUS316
Applications:
◆ Auto cooling pump
◆ Household pump
◆ General pump
◆ Small-typed centrifugal pump
Specification:
Temperature: - 35℃ ~ 135℃
Pressure : ≤0.3MPa
Speed : φ12≤7200r/min;φ16≤6500r/min ;
φ20≤5000r/min
