Model	d	A	C	D1	D2	D3
C12D	12	0.4+8.9	7.6	26.5	30	35
C16R-0	15.918	0.4+11.84	7.1	31.5	34.2	39.5
C16R-1	15.918	0.4+10.7	8.2	31.5	36.5	41
C16R-2	16	0.4+10.7	8.2	31.5	38.1	43.6
C17R-0	17	0.4+13.6	8	33.5	35	41

Operation Conditions：

Temperature：-35℃~ 135℃
Pressure : ≤0.3MPa
Speed : φ12≤7200r/min；φ16≤6500r/min；φ17≤5800r/min
Medium：clean water, gas engine antifreeze

Standard Materials：

Parts & Spring ：Stainless Steel
Rubber parts ：NBR & HNBR
Stationary Ring ：Carbon/Sillicon Carbide
Rotary Ring ：Sillicon Carbide
Metal parts：SUS 304 / SUS316

Applications：

◆ Auto cooling pump
◆ Household pump
◆ General pump
◆ Small-typed centrifugal pump

Specification:

Temperature： - 35℃ ~ 135℃
Pressure : ≤0.3MPa
Speed : φ12≤7200r/min；φ16≤6500r/min；
φ17≤5800r/min
