ERVING SEAL ENTERPRISES CO., LTD
Model | d | A | C | D1 | D2 | D3 |
7CA-0 | 12.7 | 7.6 | 9.8 | 25 | 39.5 | 43.6 |
7CA-2 | 12 | 9.3 | 8 | 25 | 30 | 35 |
7CA-7 | 12 | 9.3 | 8 | 25 | 38.1 | 43.6 |
7CA-11 | 12 | 9.3 | 7.6 | 25 | 30 | 35 |
7CA-13 | 12 | 8.8 | 6.7 | 25 | 30 | 35 |
7CH-0 | 15.918 | 10.9 | 8 | 33 | 35 | 41 |
7CH-1 | 15.918 | 10.9 | 8 | 33 | 36.5 | 41 |
Operation Conditions:
Temperature:-35℃~ 135℃
Pressure:≤0.3MPa
Speed : φ12≤6500r/min; φ16≤6000r/min;
Medium:clean water, gas engine antifreeze
Standard Materials:
Parts & Spring :Stainless Steel
Rubber parts :NBR & HNBR
Stationary Ring :Carbon/Sillicon Carbide
Rotary Ring :Ceramic/Sillicon Carbide
Metal parts:SUS 304 / SUS316
Applications:
◆ Auto cooling pump
◆ Household pump
◆ General pump
◆ Small-typed centrifugal pump
Specification:
Temperature: - 35℃ ~ 135℃
Pressure : ≤0.3MPa
Speed : φ12≤6500r/min; φ16≤6000r/min;
