ERVING SEAL ENTERPRISES CO., LTD
Model | d | A | C | D1 | D2 | D3 |
7C-0 | 15.918 | 12.3 | 7.1 | 33 | 34.2 | 39.5 |
7CC-a | 15.918 | 11.84 | 5.7 | 33 | 34.2 | 39.5 |
7C-0 | 17 | 13.6 | 8 | 33 | 35 | 41 |
Operation Conditions:
Temperature:-35℃~ 135℃
Pressure : ≤0.3MPa
Speed : φ16≤6000r/min; φ17≤5300r/min
Medium:clean water, gas engine antifreeze
Standard Materials:
Parts & Spring :Stainless Steel
Rubber parts :NBR & HNBR
Stationary Ring :Carbon/Sillicon Carbide
Rotary Ring :Ceramic/Sillicon Carbide
Metal parts:SUS 304 / SUS316
Applications:
◆ Auto cooling pump
◆ Household pump
◆ General pump
◆ Small-typed centrifugal pump
Specification:
Temperature: - 35℃ ~ 135℃
Pressure : ≤0.3MPa
"Speed : φ16≤6000r/min; φ17≤5300r/min
"
